Specifications
Premium quick coupling system with nominal diameter 7,8 for pneumatic and fluid handling applications up to 35 bar. Coupling system with standard European profile. Available made of brass/steel or stainless steel.
Material | AISI 316 L | ||
Connection Thread Size (mm) | na | ||
Type | Plug | ||
Version | Single Shut-Off | ||
Valve Included | No | ||
Hex Size | 24 mm | ||
Flow Rate | 1800 L/min |
Connection Type | Male Thread - parallel | ||
Hose I.D. | na | ||
Connection Thread Size (inch) | 1/2 | ||
Diameter | 7,4 nom | ||
Length | 38 mm | ||
Maximum Operating Pressure | 35 bar |
