Bore diameter bearing | d | 60 | mm |
Height | T | 23 | mm |
Basic dynamic load rating, radial | Cr | 483,000 |
Outside diameter bearing | D | 95 | mm |
Width inner ring | B | 22 | mm |
Basic static load rating, radial | C0r | 805,000 |
Edge Spacing | r1smin | 0.60 | mm |
Connection measure Inner ring | da max | 77 | mm |
Connection diameter | Db min | 87 | mm |
Ball diameter | dK | 86 | mm |
Plane Surface Spacing | s | 5 | mm |
Bore diameter bearing, lower tolerance | dUT | -0.02 | mm |
Height, upper tolerance | TOT | 0.25 | mm |
Width inner ring, lower tolerance | BUT | -0.30 | mm |
Width Outer ring | C | 22 | mm |
Tilt angle | α | 1.30 | ° |
Outside diameter, lower tolerance | Do UT | -0.02 | mm |
Height, lower tolerance | TUT | -0.25 | mm |
Manufacturer | Part Number |
---|---|
Elges | GE60SW |
SKF | GAC60 F (SKF) |
