| connection thread lubrication | M6 | ||
| Thickness of flange | C1 | 9.50 | mm |
| Outside diameter locking device | d3 | 28.40 | mm |
| Distance raceway | A2 | 17 | mm |
| Bore diameter | d | 15 | mm |
| Total height unit | U | 39.10 | mm |
| Basic static load rating, radial | C0r | 4,750 |
| Flange width | a | 76 | mm |
| Basic dynamic load rating, radial | Cr | 9,800 | |
| Fatigue load limit, radial | Cur | 248 | N |
| Distance fixing bore | J | 54 | mm |
| Number of screwing holes | n | 4 |
| Fixing bore | N | 11.50 | mm |
