PS1-E196 Parker Hannifin

Parker PS1-E196

Name: PS1-E196 Parker
Brand: Parker
SKU: 553905-en-usd
Price: 170.63 USD
Availability: InStock

$170.63 12 pcs. with 1 to 3 days delivery to United States

Specifications

The PS1E series valve is an internal air piloted stacking style valve with plug-in coils. Available valve functions are 3/2, and 5/2 single and double solenoid. Each valve is individually wired. Surge suppressors with an indicating LED are available.

max. flow	0.16 cv, n/a
Seal	poppet: polyurethane \| seals: nitrile (buna n)

Weight	500g

Technical data

port type		push-in Ø 6mm
Series		electro-pneumatic module
number of positions		2
actuation type		solenoid air operated
Mounting type		stacking
Port size		6mm
maximum flow rate		0.16 cv, n/a
Electrical connection		terminal strip
minimum operating pressure		40 psig
media		air
power consumption		1.2w, 1.6va
seal material		poppet: polyurethane \| seals: nitrile (buna n)

function		4/2 way double solenoid
valve type		-
Number of ports		4
override functionality		non-locking and locking manual overrides
specifications met		n/a, ip20
minimum flow rate		0.14 cv
Input voltage		12 to 48vdc, 120/240vac
pressure rating		40 to 120 psig, 3 to 8.2 bar
Operating temperature		-15 to +60 °c, +5 to +140 °f
Lubricant		lubricated or non-lubricated air
body material		glass filled polyamide
