Standard | iso 5599-1 | ||
controlled port | 2, 4 | ||
regulation range min. | 0.5 bar | ||
min. ambient temperature | -15 °c | ||
Medium | compressed air | ||
oil content of compressed air min. | 0 mg/m³ | ||
nominal flow qn | 1070 l/min | ||
Weight | 1.6 kg | ||
seal material | butadiene rubber |
frame size | iso 2 | ||
working pressure max | 12 bar | ||
regulation range max. | 8 bar | ||
max. ambient temperature | 50 °c | ||
max. particle size | 5 µm | ||
oil content of compressed air max. | 5 mg/m³ | ||
tightening torque for mounting screws | 5 nm | ||
Housing Material | aluminum |
Stock | Ask for quotation |
---|---|
Part number | R422103094 |
Manufacturer | Aventics |
Quantity | Unit Price |
---|---|
1+ | $606.11 |
